Materials and specifications
Plastic parts: PA66 UL94V - 0
Terminal: brass, Tin plating
Spring: steel

performance

Pitch:5.08mm
Rated voltage/current: 300 V/ 15A
Temperature: - 40 ℃ ~ + 105 ℃
The withstand voltage: AC1500V/Min
Insulation resistance: 500 mΩ / DC500V

Wire range:24-12 AWG

Shenzhen StarPai Technology Co., Ltd. is located in Shenzhen,China. Our company specializes in terminals, PCB connectors, terminal components, cable and has a complete and scientific quality management system, integrity, strength and quality of products recognized by the industry. Welcome all friends to require products for your needs. guidance and business negotiations.

Product series:
1. European wiring terminal - connector spacing: (2.5 / 3.5 / 3.81 / 5.0 / 5.08 / 6.35 / 9.5 / 10.06mm, etc.); wiring range from 0.25 mm2 ~ 2.5mm2

2. Fence-type terminals - connector spacing: (7.62 / 8.25 / 8.5 / 9.5 / 10.0 / 11.0mm, etc.); wiring range from 1mm2 ~ 35mm2

3. Plugable terminals - connector spacing: (2.54 / 3.5 / 3.81 / 5.08 / 7.5 / 10.16mm, etc.); wiring range from 0.25 mm2 ~ 2.5mm2

4. Spring-type terminals - connector spacing: (2.5 / 2.54 / 3.5 / 3.81 / 5.0 / 7.5 / 7.62 / 10.0mm, etc.); wiring range from 0.25 mm2 ~ 16mm2

5. Rail-type terminal blocks - connector spacing: wiring range 0.14mm2 ~ 50mm2

6. Feed through terminal block - connector spacing: (8.0mm / 10.0mm/ 12.0mm/ 14.0mm/ 16.0mm, etc.); wiring range from 0.25 mm2 ~ 16mm2

7. USB cable, USB A / M, Micro B / M, HDMI A / M, RJ45 LAN wire and so on

8. other (detailed needs or OEM, please consult our company)
