    LED SMD Terminal Block with speedy and safety terminal function 1 Pole / 2 Pole / 3 Pole pitch:4.0mm/0.157in

    Ask Lasest Price
    Brand Name : starpai
    Model Number : 151-04-01P
    Certification : UL,Rohs
    Price : us 0.1- us 1.0
    Payment Terms : T/T
    Supply Ability : 500000 pcs per month
    Delivery Time : 15-25 work days
    • Product Details
    • Company Profile

    LED SMD Terminal Block with speedy and safety terminal function 1 Pole / 2 Pole / 3 Pole pitch:4.0mm/0.157in



    SMD PCB terminal blocks from starpai with pushbutton and push-in CAGE CLAMP® connection, supplied in tape-and-reel packaging for automated assembly or bulk for need.

    • Height of just 4.5 mm minimises on-board LED shadowing
    • Suitable for lead-free, reflow-soldering profiles per DIN EN 61760-1 and IEC 60068-2-58 up to max. 260°C peak temperature
    • Colour: white
    • Pin spacing: 4mm
    • Tin-plated copper alloy contacts
    • 1-way terminal block
    • Terminates conductors from 24 to 18 AWG (0.2 to 0.75mm²)
    • Push-buttons for easy connection and removal of all types of conductors
    • Group arrangement is possible without losing any poles
    Quality LED SMD Terminal Block with speedy and safety terminal function 1 Pole / 2 Pole / 3 Pole pitch:4.0mm/0.157in for sale
