Brand Name : | STARPAI |
Certification : | EC,UL,Rohs |
Model Number : | DTB 5.08-203-3 |
Price : | 4.86 USD/PCS |
Delivery Time : | 25 days after 100% T/T payment |
Payment Terms : | T/T, L/C, D/A, T/T, Western Union, MoneyGram |
Supply Ability : | 100000K/pcs |
Materials and specifications
Plastic parts: PA66 UL94V - 0
Terminal: brass, Tin plating
Spring: steel
performance
Pitch:5.08mm
Rated voltage/current: 300 V/ 15A
Temperature: - 40 ℃ ~ + 105 ℃
The withstand voltage: AC1500V/Min
Insulation resistance: 500 mΩ / DC500V
Wire range:24-12 AWG
![]() |
